Description
SPECIFICATION
APPLICATION
CONSTRUCTION
| PRODUCT CODE |  Inner Diameter |
 Outer Diameter |
 Working Pressure |
 Min Bend Radius |
Standard Pack Length | |||||
| inch | mm | mm | PSI | Bar | mm | meter | ||||
| JET-3K-32 | 2 | 51 | 86 | 3000 | 210 | 900 | 60 | |||
| JET-3K-40 | 2 1/2 | 64 | 100 | 3000 | 210 | 900 | 60 | |||
| JET-3K-48 | 3 | 76 | 111 | 3000 | 210 | 1200 | 60 | |||
| JET-3K-64 | 4 | 102 | 139 | 3000 | 210 | 1400 | 60 | |||
| JET-3K-80 | 5 | 127 | 187 | 3000 | 210 | 1500 | 60 | |||
| JET-3K-96 | 5 | 152 | 216 | 3000 | 210 | 1600 | 60 | |||
High pressure sea water jetting for offshore drilling operation.
Tube: NBR, black, oil, seawater resistant.
Reinforcement: Multiple layer of high tensile steel cable.
Cover: Black, neoprene, oil, ozone, resistant.
Temperature: -30°C to 100°C
Reinforcement: Multiple layer of high tensile steel cable.
Cover: Black, neoprene, oil, ozone, resistant.
Temperature: -30°C to 100°C
