Description
SPECIFICATION
APPLICATION
CONSTRUCTION
| PRODUCT CODE |  Inner Diameter |
 Outer Diameter |
 Working Pressure |
 Min Bend Radius |
Standard Pack Length | |||||
| inch | mm | mm | PSI | Bar | mm | meter | ||||
| NGSAND-150D-8 | 1/2 | 13 | 31 | 150 | 10 | 128 | 60 | |||
| NGSAND-150D-12 | 3/4 | 30 | 38 | 150 | 10 | 205 | 60 | |||
| NGSAND-150D-16 | 1 | 40 | 41 | 150 | 10 | 305 | 60 | |||
| NGSAND-150D-16 | 1 | 40 | 48 | 150 | 10 | 305 | 60 | |||
| NGSAND-150D-20 | 1 1/4 | 48 | 55 | 150 | 10 | 305 | 60 | |||
| NGSAND-150D-24 | 1 1/2 | 54 | 60 | 150 | 10 | 460 | 60 | |||
| NGSAND-150D-32 | 2 | 71 | 75 | 150 | 10 | 510 | 60 | |||
Delivery of sand, shot-blasting operation. Design for abrasive materials that requires high velocity discharge services.
Tube: NR/ SBR, black.
Reinforcement: Two plies synthetic textile cord.
Cover: Black. SBR rubber. Abrasion, environment resistant.
Temperature: -40°C to 70°C
Reinforcement: Two plies synthetic textile cord.
Cover: Black. SBR rubber. Abrasion, environment resistant.
Temperature: -40°C to 70°C
