Description
SPECIFICATION
APPLICATION
| Part Label | Hose Size (mm) | Thread | S | H1 | H2 | |
| Inch | mm | mm | mm | mm | mm | |
| B4FJISZ4 | 1/4 | 6.4 | 1/4-18 | 19 | 19 | 19 |
| B6FJISZ6 | 3/8 | 9.5 | 3/8-19-18 | 23 | 22 | 22 |
| B8FJISZ8 | 1/2 | 12.7 | 1/2-14 | 22 | 27 | 27 |
| B12FJISZ12 | 3/4 | 19.1 | 3/4-19 | 26 | 32 | 32 |
| B16FJISZ16 | 1 | 25.4 | 1-11 | 31 | 38 | 38 |
| B16FJISZ16 | 1 1/4 | 31.1 | 1 1/4-11 | 45 | 50 | 50 |
- HOSE TYPE:
UB1, UB2, UB1-HT, UB2-HT, UB19, UB17, UB16, UM4, UPW4000, UPW3000 - Non Skive Insert
- Ferrule UFB Series
